Check before asking 'What TV, Speakers, Subs fit blah blah'. A Sticky post may also exist helping with buying decisions. Hey guys,I am helping someone setup a 4 projector system (Ricoh WX4141n). They have a NVIDIA Quardro K5000 on their hands but that is about all they got in terms of resources. Do you know of any affordable edge blending and web cam calibrating software to blend these 4 projectors together?We explored VIOSO ($4000 wow.), Warpalizer (won't install), and NTHUSISM (didn't work, also the build may be used in commercial so a moral issue, also their parent company software probably doesn't work either).You guys have any software you recommend or currently use?. The easiest way to do this is to use a nvidia quadro card (K5000 for sure will work, I've set up multiple sites using these exact cards), and a projector that supports internal edge blending, so you don't have to use any additional software.
Scalable Edge Blending Software
If the later isn't within scope for whatever reason, than you'll need something external to manipulate the image (mostly just brightness at this point, since a lot can be done in the nvidia settings).I've used multiple types with great success, projection design's warp/blend box (now Barco), christie digital's internal, scalable display, and a couple others. Bottom line is they aren't cheap. I haven't used any of what you've mentioned. Osx86 8f1111 with wesley patches. Nvidia mosaic let's you do overlap, this will create hotspotting where the two projectors overlap, however that's what the internal settings for the projector can compensate for.You overlap the projectors your set amount, then use nvidia utility to tell it you've overlapped 'x' pixels.
Matrox Edge Blending Software
I prefer to use the nvidia command line utility, so I can just create a batch file to run in case it ever breaks, and I need to reapply the mosaic settings. (PS, don't look for documentation on the command line utility, it doesn't really exist). Once you're in mosaic, you can put whatever you want wherever you want, they are seen as one logical desktop. You can arrange things however you want to, just like on the monitor in front of you.
What I've done in the past for that type of thing is make a pixel for pixel desktop background, putting the logos you want to use in that background image. Making it pixel for pixel let's you precisely place them, without any scaling/stretching. If you do this, be sure to calculate the overlap in your edge blended areas, as that overlap decreases your overall pixel count.
About LightMagic edge blending software.LM Fusion software is an edge blending software which applied to multi-projection and large screen projection field. LM Fusion software devotes itself to overcome the stability and compatibility of edge blend software all the time.
Our LM Fusion software received good feedback from the market after the long-term software development and scientific software testing. Our LM Fusion software has never appear the problem of quality and stability since it put into the market and gradually it becomes the model of the industry.With the development of the projection technology, the software of LM Fusion series and LM Dome Fusion software have been successfully applied to planning library, planetarium, museum, projection sand table, 3D seamless theatre, theme park, exhibition hall, stage and so on. They also support curve screen, 360 degree circular screen, spherical screen, Dome and various applications.
Audience can enjoy the HD and lifelike visual enjoyment even by the low-end LCD projectors. Flexible edge blending software01.It supports the projectors with various resolutions—Projectors with any resolutions can realize the HD edge blending effect and including the projectors of non-standard resolutions.02.It supports the projectors with any kinds of installation—Projectors can be installed arbitrarily according to the place limitation and project requirements. Our LM Fusion software can be applied to the vertical installation, horizontal installation and even the vertical and horizontal mixing installation.03.It supports random arrangement of multi-projectors—LM Fusion software will not limit the projector’s number of each row and column. The number of the projectors of each row can be different.04.It supports low-end LCD projectors— There are four colors(red, green, blue, gray) and each color has 9 –level curve to be adjust. It also supports equation curve and free curve to make sure that the low-end LCD projectors can present a perfect fusion effect to audience.
Professional technology01.Geometry Correction—It supports the grid moving accuracy of 0.5 pixels, 1.0 pixels, 4.0 pixels and 8.0 pixels. There are four correction modes (point, row, column, corner). It also can upload the self-define image to be used for matching the digital content with the real model. It is widely used in digital sand table.02.Color Uniform- There are four colors(red, green, blue, gray) and each color has 256 brightness levels can be adjust independently.
By taking advantage of the ColorRemap technology, engineers can adjust the brightness and color of different projectors to the same level and it makes the post-maintenance much easier.03.Edge Blending—Each projector can self-define the width and number of the fusion bands. The unique free curve and equation curve of LM Fusion can remove the fusion bands completely.
Easy to operate01.Integrated operation panel- When LM Fusion software is ready for work, the first step is to add the IP addresses of all fusion servers to get the information of all servers and projectors. The IP address will display on the software’s control panel orderly according to the real arrangement. Controlling 100 projectors is as simple as controlling 1 projector by using the integrated control panel.02.The creative UI design—All the function buttons, page layout and operation progress meet common people’s thinking habits and the operation progress is clear. The engineers can operate individually after the simple training and construction practice.
Professional technology and widely usedThe built-in NSMP Fusion Player—LM edge blending software can decode various kinds of video files internally and the advantage of the internal decoding is that it can synchronize multiple fusion servers’ video play in LAN. The accuracy can achieve 1/1000 a second. It will hardly appearthe problem of image tearing.Based on GPU—The development of LM edge blending software is based on the GPU and it all operates in GPU when the software starts, it seldom take up the CPU space. If the high-performance graphics workstation is used,the single fusion server can output 12 projectors. For some small exhibitions, one server can meet their needs and the system will operate more stable.
